Art. no. 72813003
In addition to the voluntary manufacturer’s guarantee, you can rely on the multi-award-winning high quality standards and durability of hansgrohe products.
Water is life. Water is our passion. With our sustainable product solutions, we combine water- and energy-saving technologies and protect people, the environment, and our planet.
No matter your plans, we are here for you and happy to offer support, especially when it comes to help, service, guarantees or spare parts. Get in touch now!
WaterMark™ is a product quality certification mark provided by independent certifying authorities. It confirms the product complies with the Plumbing Code of Australia and the relevant Australian Standards, which relate to product quality, including heal
Item no. | DescriptionArticle no. |
---|
1 | spout cpl.92731000 |
2 | O-ring 11x298127000 |
3 | filter97735000 |
4 | handspray92732003 |
5 | non return valve95333000 |
6 | non return valve95332000 |
7 | aerator laminar M22x1 (15 l/min)95909000 |
8 | O-ring 20x198140000 |
9 | service tool95910000 |
10 | set of locating rings (110° / 150°)98486000 |
11 | O-ring 16x1,598483000 |
12 | set of lever collars98365000 |
13 | O-ring 21x2,598211000 |
14 | handle92691000 |
15 | screw cover96338000 |
16 | flange95498000 |
17 | O-Ring 32x298193000 |
18 | nut97209000 |
19 | cartridge, assy92730000 |
20 | locking screw for handle95140000 |
21 | seal95008000 |
22 | seal92582000 |
23 | support97523000 |
24 | fixing set (Ø 34)95049000 |
25 | lever collar97548000 |
26 | weight98551000 |
27 | hose 1,50 m95507000 |
28 | connection hose 600 mm M10x195561000 |
29 | O-ring 8x1,7597827000 |
30 | connection hose 900 mm M8x0,75 G½97489000 |
31 | O-ring 7x1,598422000 |
